Used MesPack H220 FED Horizontal Hot Fill Pouch System

Manufacturer:Mespack

Model:H-220 FED

Year:2011

Availability: Available

Location:Evansville, IN

Equipment #:D7781

Equipment Sourcing

Can't find what you're looking for?
  • Let our team of experts find the right equipment for you from our network of over 4,000 dealers and over 65,000 equipment owners.

Shop Services

Projects Big or Small
  • Proof-of-concept
  • Integration
  • Set-to-size

Description

Used MesPack H-220-FED Horizontal Form Fill and Seal Machine with:

  • Hot Fill Pouch System
  • 4 filling heads
  • Last running Hot Fill 4 ounce pouches
  • Allen Bradley CompactLogix L43 PLC
  • Includes 2010 TAEevo Chiller S/N: 2200160530
  • Independent electrical cabinet
  • Independent unwind system
  • Automatic adjustment control of seal jaws position
  • Automatic hole punch correction system for stand up pouches
  • Servo driven change over system for forming plough (to be verified)
  • Triple pouch opening system through vacuum, air jet & mechanical device (to be verified)
  • 3 different filling stations (to be verified)
  • Cam driven walking beam
  • Pouch grippers engineered to hold up to 2 Kg
  • Static pouch stretching prior to sealing
  • Pouch reject station
  • PLC automatic lubrication system (to be verified)
  • Servo driven stroke indexing system by rollers
  • There is hardly any product which cannot be packed into a sachet made of flexible film. Solid, liquid, powders, granules, everything is possible on a Mespack machine which enables you to present your product in most innovative shapes and using latest techniques
  • Pouch size minimum - 70 mm x 100 mm
  • Pouch size maximum - 110 mm x 300 mm
  • Gusset Min and Max - 40 mm / 120 mm
  • Maximum volume - 500 c.c.
  • Filling station (not filling heads) - 3 total
  • Output (packages per minute) - 130 / 140 Note: filling speed will depend on product and film characteristics
  • Type of pouch - Stand up (Doypack)
  • APV WS303000044 Sanitary Centrifugal Pump
  • FLOWMETER DN-15 (TRI CLAMP) approximate filling capacity:
    • Minimum 50ml
    • Maximum 250ml
  • Unit was in operating condition when removed from service
  •
